Duplicate assets are rarely an issue – unless you’re working on a large-scale app with multiple business lines. Unfortunately, that was exactly our situation. The impact on package size wasn’t huge (a few hundred KB), but for anyone doing size optimization, every byte counts.

How to Deduplicate?

The key is intercepting access to assets – specifically, AssetManager. Booster’s approach uses a Transformer to replace AssetManager method call instructions with an injected ShadowAssetManager. Here’s the code:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
public final class ShadowAssetManager {

    /**
     * Shadow Asset => Real Asset
     */
    private static final Map<String, String> DUPLICATED_ASSETS = new ArrayMap<String, String>();

    public static InputStream open(final AssetManager am, final String shadow) throws IOException {
        final String name = DUPLICATED_ASSETS.get(shadow);
        return am.open(null != name && name.trim().length() > 0 ? name : shadow);
    }

    private ShadowAssetManager() {
    }

}

Is that all? Not quite – the DUPLICATED_ASSETS map above is still empty. The next step is to build this duplicate assets mapping during the build process:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
fun BaseVariant.removeDuplicatedAssets(): Map<String, String> {
    val output = mergeAssets.outputDir
    val assets = output.search().groupBy(File::md5).values.filter {
        it.size > 1
    }.map { duplicates ->
        val head = duplicates.first()
        duplicates.takeLast(duplicates.size - 1).map {
            it to head
        }.toMap(mutableMapOf())
    }.reduce { acc, map ->
        acc.putAll(map)
        acc
    }

    assets.keys.forEach {
        it.delete()
    }

    return assets.map {
        it.key.toRelativeString(output) to it.value.toRelativeString(output)
    }.toMap()
}

Then, in the Transformer, we modify ShadowAssetManager by injecting the asset mapping into its clinit (static initializer), populating DUPLICATED_ASSETS:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
class ShadowAssetManagerTransformer : ClassTransformer {

    private lateinit var mapping: Map<String, String>

    override fun transform(context: TransformContext, klass: ClassNode): ClassNode {
        if (klass.name == SHADOW_ASSET_MANAGER) {
            klass.methods.find {
                "${it.name}${it.desc}" == "<clinit>()V"
            }?.let { clinit ->
                klass.methods.remove(clinit)
            }

            klass.defaultClinit.let { clinit ->
                clinit.instructions.apply {
                    add(TypeInsnNode(Opcodes.NEW, "java/util/HashMap"))
                    add(InsnNode(Opcodes.DUP))
                    add(MethodInsnNode(Opcodes.INVOKESPECIAL, "java/util/HashMap", "<init>", "()V", false))
                    add(VarInsnNode(Opcodes.ASTORE, 0))
                    mapping.forEach { shadow, real ->
                        add(VarInsnNode(Opcodes.ALOAD, 0))
                        add(LdcInsnNode(shadow))
                        add(LdcInsnNode(real))
                        add(MethodInsnNode(Opcodes.INVOKEVIRTUAL, "java/util/HashMap", "put", "(Ljava/lang/Object;Ljava/lang/Object;)Ljava/lang/Object;", false))
                        add(InsnNode(Opcodes.POP))
                    }
                    add(VarInsnNode(Opcodes.ALOAD, 0))
                    add(MethodInsnNode(Opcodes.INVOKESTATIC, "java/util/Collections", "unmodifiableMap", "(Ljava/util/Map;)Ljava/util/Map;", false))
                    add(FieldInsnNode(Opcodes.PUTSTATIC, SHADOW_ASSET_MANAGER, "DUPLICATED_ASSETS", "Ljava/util/Map;"))
                    add(InsnNode(Opcodes.RETURN))
                }
            }
        } else {
            klass.methods.forEach { method ->
                method.instructions?.iterator()?.asSequence()?.filterIsInstance(MethodInsnNode::class.java)?.filter {
                    ASSET_MANAGER == it.owner && "open(Ljava/lang/String;)Ljava/io/InputStream;" == "${it.name}${it.desc}"
                }?.forEach {
                    it.owner = SHADOW_ASSET_MANAGER
                    it.desc = "(L$ASSET_MANAGER;Ljava/lang/String;)Ljava/io/InputStream;"
                    it.opcode = Opcodes.INVOKESTATIC
                }
            }
        }

        return klass
    }
}

The ShadowAssetManagerTransformer above rewrites the static initializer of ShadowAssetManager to populate DUPLICATED_ASSETS with the duplicate asset mappings. When decompiled, the result looks like this:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
public final class ShadowAssetManager {

    private static final Map<String, String> DUPLICATED_ASSETS;

    static {
        Map<String, String> var0 = new HashMap<String, String>();

        var0.put("assets-1-1", "assets-1");
        var0.put("assets-1-2", "assets-1");
        var0.put("assets-1-3", "assets-1");

        var0.put("assets-2-1", "assets-2");
        var0.put("assets-2-2", "assets-2");

        ......

        var0.put("assets-N-1", "assets-N");
        var0.put("assets-N-2", "assets-N");
        ......
        var0.put("assets-N-n", "assets-N");

        DUPLICATED_ASSETS = Collections.unmodifiableMap(var0)
    }

}

A Minor Limitation

This approach handles most duplicate assets, but fonts are an exception – font loading doesn’t go through the Java-layer AssetManager. If you’re curious, take a look at Typeface.

Summary

Booster’s asset deduplication works in three steps:

  1. Group assets by md5sum and build a mapping of duplicates;
  2. Replace all AssetManager.open(String): InputStream call instructions with ShadowAssetManager.open(AssetManager, String): InputStream;
  3. Modify the static initializer of ShadowAssetManager to populate ShadowAssetManager.DUPLICATED_ASSETS with the duplicate mapping;

Extended Use Cases

Intercepting AssetManager.open(String): InputStream opens the door to more than just deduplication – you can also compress assets to further reduce package size. The idea is straightforward: since AssetManager.open(String) returns an InputStream, you can substitute it with a ZipInputStream. Here’s the approach:

  1. After mergeAssets, ZIP-compress the assets;
  2. Intercept AssetManager.open() and return a ZipInputStream from ShadowAssetManager.open();

The entire process is completely transparent to the app – seamless.
