Java developers should be familiar with SPI (Service Provider Interface). Whether it’s the JDK, Gradle, or various third-party frameworks, SPI is widely used to provide extensibility. So why is it so rarely seen on the Android platform?

I believe there are two reasons:

  1. Android and Java applications have different distribution models

    Java applications are distributed as JARs, making them very easy to extend. But once an Android APK is built, it’s essentially frozen. Achieving extensibility requires non-standard approaches.

  2. SPI performance on Android is concerning

    Since Android devices generally have lower performance than PCs, combined with Android’s ANR mechanism, SPI can easily cause jank or even ANR on Android.

What Is SPI

The official Java definitions are:

Service

A set of programming interfaces and classes that provide access to specific application functionality and features.

Service Provider Interface (SPI)

A set of public interfaces and abstract classes defined by the Service.

Service Provider

An implementation of the SPI.

SPI’s Performance Deficiency

Java’s native SPI searches for SPI configuration files under META-INF/services/ through the ClassLoader in the CLASSPATH, then reads their contents. This requires parsing JAR files (on Android, parsing APK files), which involves iterating through every entry in the entire JAR/APK. This makes it extremely time-consuming (I’ve been burned by this before).

Why Choose SPI Anyway

If SPI performs so poorly on Android, why use it at all?

During application development, architectural requirements inevitably demand compile-time extensibility – interface-implementation separation, one interface with multiple implementations that need dynamic discovery, reverse dependencies, and so on. Compared to Dagger, SPI is simple, natively supported by the API, and doesn’t require any additional third-party libraries.

How to Optimize

Having chosen SPI, how do we solve its performance bottleneck on Android? The answer is: eliminate I/O.

The approach is straightforward. Let’s walk through it using reverse thinking:

  1. Generate a service registry – ServiceRegistry – during the build phase
  2. Replace all ServiceLoader invocations in the code with calls to a custom ShadowServiceLoader
  3. ShadowServiceLoader retrieves the Service Provider Interface to Service Provider mappings from ServiceRegistry

But there are several questions:

  1. Does ServiceRegistry store mappings of Class<Service> to Class<ServiceProvider>, or something else?

    It could be a Class mapping, but instantiating a Service Provider would then require reflection.

  2. Can ServiceLoader completely avoid reflection when loading through ServiceRegistry?

    Yes, it can. In that case, ServiceRegistry needs to store mappings from Class<Service> to Creator<ServiceProvider>. The content looks roughly like this:

    1
    2
    3
    4
    5
    public class ServiceRegistry {

        static final Map<Class<?>, List<Callable<?>>> registry = new HashMap<>();

    }

    A Creator looks roughly like this:

    1
    2
    3
    4
    5
    6
    7
    8
    public class ServiceProviderCreator implements Callable<ServiceProvider> {

        @Override
        public ServiceProvider call() {
            return new ServiceProvider();
        }

    }

  3. How do we register the mappings into ServiceRegistry? Using a static initializer block:

    1
    2
    3
    4
    5
    6
    7
    8
    9
    public class ServiceRegistry {

        static final Map<Class<?>, List<Callable<?>>> registry = new HashMap<>();

        static {
            register(InterfaceA.class, new InterfaceACreator())
        }

    }

Example

HttpProtocolConfig.kt

1
2
3
4
5
interface HttpProtocolConfig {

    fun getProtocol(): String

}

HttpProtocolConfigProvider.kt

1
2
3
4
5
6
@Service(HttpProtocolConfig.class)
class HttpProtocolConfigProvider : HttpProtocolConfig {

    override fun getProtocol() = if (BuildConfig.DEBUG) "http" else "https"

}

HomePresenter.kt

1
2
3
4
5
6
7
8
9
class HomePresenter : Presenter() {

    private val config = ServiceLoader.load(HttpProtocolConfig::class.java).first()

    fun loadConfig() {
        println(config.getProtocol())
    }

}

Source Code

This solution is fully open-sourced at: https://github.com/johnsonlee/service-loader-android

Example code: https://github.com/johnsonlee/service-loader-android/tree/master/example
