Inside the Kotlin Compiler Architecture

One weekend I was browsing GitHub at home when a WeChat message popped up: “Hey, how do Kotlin compiler plugins like ksp and allopen actually get loaded? I’ve been staring at the code for hours and I’m totally lost.” I thought to myself, “It’s probably SPI-based plugin loading, nine times out of ten.” So I quickly pulled up the JetBrains/Kotlin repo, found KotlinGradleSubplugin.kt, and sent him a screenshot of the code, pretending I knew it all along.

“I’ve already seen that. What I want to know is when exactly the all-open plugin modifies class modifiers.”

Well… I couldn’t bluff my way through that one. So I cloned the JetBrains/Kotlin repo and started digging in earnest.

PluginCliParser

After some educated guessing, I found this code in PluginCliParsers.kt:

object PluginCliParser {

    @JvmStatic
    fun loadPlugins(pluginClasspaths: Iterable<String>?, pluginOptions: Iterable<String>?, configuration: CompilerConfiguration) {
        val classLoader = URLClassLoader(
            pluginClasspaths
                ?.map { File(it).toURI().toURL() }
                ?.toTypedArray()
                ?: emptyArray(),
            this::class.java.classLoader
        )

        val componentRegistrars = ServiceLoaderLite.loadImplementations(ComponentRegistrar::class.java, classLoader)
        configuration.addAll(ComponentRegistrar.PLUGIN_COMPONENT_REGISTRARS, componentRegistrars)

        processPluginOptions(pluginOptions, configuration, classLoader)
    }

}

Just as I expected – plugins are loaded via SPI. The only difference is that instead of using ServiceLoader directly, they use ServiceLoaderLite.kt. Let’s see how it differs from the JDK’s ServiceLoader.

ServiceLoaderLite

The code comment tells the whole story – it’s because of a JDK 8 bug: ServiceLoader file handle leak.

/**
 * ServiceLoader has a file handle leak in JDK8: https://bugs.openjdk.java.net/browse/JDK-8156014.
 * This class, hopefully, doesn't. :)
 */
object ServiceLoaderLite {
    private const val SERVICE_DIRECTORY_LOCATION = "META-INF/services/"

    ...

    fun <Service> loadImplementations(service: Class<out Service>, classLoader: URLClassLoader): List<Service> {
        val files = classLoader.urLs.map { url ->
            try {
                Paths.get(url.toURI()).toFile()
            } catch (e: FileSystemNotFoundException) {
                throw IllegalArgumentException("Only local URLs are supported, got ${url.protocol}")
            } catch (e: UnsupportedOperationException) {
                throw IllegalArgumentException("Only local URLs are supported, got ${url.protocol}")
            }
        }

        return loadImplementations(service, files, classLoader)
    }

    ...

    private fun findImplementationsInJar(classId: String, file: File): Set<String> {
        ZipFile(file).use { zipFile ->
            val entry = zipFile.getEntry(SERVICE_DIRECTORY_LOCATION + classId) ?: return emptySet()
            zipFile.getInputStream(entry).use { inputStream ->
                return inputStream.bufferedReader().useLines { parseLines(file, it) }
            }
        }
    }

    ....

}

Looking at the implementation, ServiceLoaderLite.kt iterates through all JAR files on the URLClassLoader‘s classpath to find SPI configuration files directly.

Kotlin Compiler Architecture

The entire Kotlin compiler is split into a front-end and a back-end. The back-end is mainly responsible for generating platform-specific code, while all platform-independent work is handled by the front-end. The overall structure looks like this:

There are three ways to launch the Kotlin compiler:

1. Kotlin Gradle Plugin
2. JPS (JetBrains Project System) – a build framework developed by JetBrains based on Gant, primarily used in the JetBrains IDEA product family
3. The kotlinc command

Kotlin Gradle Plugin

In everyday development, most of us use Kotlin within a Gradle environment. The startup flow of the Kotlin Gradle plugin looks like this:

Kotlin Compiler Plugin

The Kotlin compiler provides a set of extension interfaces that allow developers to build plugins on top of it. Official plugins include:

1. all-open
2. no-arg
3. SAM-with-receiver
4. Parcelable implementations generator

Beyond these, there is also Google’s KSP (Kotlin Symbol Processing API). The extension interfaces provided by the Kotlin compiler include:

1. KotlinGradleSubplugin

   This is mainly used by the Kotlin Gradle plugin. Since compiler plugins don’t depend on Gradle, the Gradle plugin needs to load them. KotlinGradleSubplugin is responsible for configuring the compiler plugin’s dependencies and any compilation options the compiler needs.

2. ComponentRegistrar

   This registers Compiler Extensions with the compiler (not the kind of Extension in Android Gradle Plugin). Compiler Extensions come in both front-end and back-end varieties.

   Front-End Extensions include:

   1. AnnotationBasedExtension
   2. CollectAdditionalSourcesExtension
   3. CompilerConfigurationExtension
   4. DeclarationAttributeAltererExtension
   5. PreprocessedVirtualFileFactoryExtension
   6. …

   Back-End Extensions include:

   1. ClassBuilderInterceptorExtension
   2. ExpressionCodegenExtension
   3. …

3. CommandLineProcessor

   This handles arguments passed to the plugin via the command line, in the format: -P plugin:<plugin-id>:<key>=<value>.

kotlinc

The rough startup process of kotlinc is shown in the diagram below. Since the full process is quite complex, some details have been omitted to help you understand how kotlinc works more quickly:

Closing Thoughts

With an understanding of the overall Kotlin compiler architecture, we can build our own plugins on top of it. Kotlin was designed with language interoperability baked into its syntax, and the compiler’s extensibility opens up virtually limitless possibilities.
