Seven years ago, when cloud computing was just getting started and Docker hadn’t yet taken off, a group of us at SAMSUNG were already tinkering with Cloud IDE. The best product in the industry at the time was Cloud 9. We referenced Cloud 9‘s architecture and adopted some of its open-source components, while building the plugin system and several UI views from scratch.

Cloud IDE

Back then, virtually every Cloud IDE solution used web technologies to build a frontend-backend separated architecture. Besides Cloud 9, there was Eclipse‘s Che. Today everyone takes Cloud IDE for granted, but at the time it was quite challenging for us. Later, for reasons unknown, Cloud 9 was acquired by AWS, and Eclipse‘s Che became a dedicated IDE for Kubernetes.

Virtualization

Why was virtualization needed? Because each user’s development environment had to be physically isolated. Since it’s an IDE, it needs to provide a build environment, so different users must be completely isolated from each other. Today this is trivially solved with Docker, but back then Docker wasn’t available in China yet. Fortunately, Linux itself provided a lightweight virtualization technology – Linux Container (LXC). So we built root filesystems based on LXC to use as virtual machine images.

Editor

An IDE needs an editor. Fortunately, Cloud 9 open-sourced a high-performance code editor called ACE Editor. That solved the infrastructure problem, but supporting various programming languages on top of this primitive editor still required a Parser, and the editor experience depended heavily on the local machine’s computing power.

UI Framework

The frontend UI was built using another open-source framework from Cloud 9 – APF, which used an XML-like template language somewhat similar to Vue. The Cloud 9 team gave it a grand name – Live Markup Language. This was arguably one of the earliest frontend MVVM frameworks. Unfortunately, the source code can no longer be found on the official website. Back then, Cloud 9 contributed it to ajaxorg. We once thought it would become a frontend standard, but it didn’t end that way.

During our technology selection, we researched many UI frameworks. We even evaluated Dart, which was considered a niche language at the time – who would have guessed it’d be put to use years later by Flutter.

Plugin System

To make the IDE extensible, the entire Cloud IDE architecture adopted a pluggable approach where the frontend loaded different modules from the backend on demand based on configuration. In an era before Promise was standardized, implementing Fork-Join in JavaScript was no easy task. Although require.js existed, it only solved part of the problem.

Web Terminal

Among all the IDE views, Terminal was the most challenging and the most interesting. To test Terminal performance, we’d run the cmatrix command to produce the falling-text effect from The Matrix. For reliability and stability testing, we’d open VIM inside the Terminal and code while testing. You can see the first version of the Web Terminal I wrote back then. The first version used a matrix canvas approach for rendering text, which turned out to be extremely sluggish when running cmatrix. In later versions, we switched to line-by-line rendering, where each line corresponds to a DIV in HTML. It didn’t seem efficient in theory, but in practice it performed much better than the matrix approach.

File Management

Managing files is a basic feature for any editor. After researching our options, we chose jsDAV and even fixed a bug along the way – 8bf6ad3. But there was another issue: all files were created by the IDE‘s server process, which meant they defaulted to the server user’s ownership. When developers logged into the Terminal with their Linux system accounts, they couldn’t modify files they’d created through the IDE if the file ownership wasn’t changed. To solve this, we built a separate daemon process that used inotify to watch filesystem changes in the project directory and chown IDE-created files to the developer’s system user.

Android Studio / IntelliJ IDE

For Cloud IDE, our instinct was that the editor should be built with JavaScript and all UI should use Web technologies. However, JetBrains‘ Projector project made me re-examine our earlier technology choices. In fact, Projector isn’t really new technology. Before working on Cloud IDE, I’d already used a similar technique – the IDE’s visual designer. Why do I say the IDE’s visual designer and Projector share the same approach?

WYSIWYG

For a visual designer, one thing must be guaranteed: what you see during development must look exactly the same as what you see in production. This is what we call WYSIWYG (What You See Is What You Get). To ensure this, the visual designer’s rendering engine must be the same one used at runtime – something only people who’ve built visual designers truly appreciate.

Take Android‘s visual designer as an example. You can write code on the left and preview the result on the right. How does this actually work? Android Studio loads the Android View system code on the PC side, then hooks the Canvas through a ClassLoader. The graphics that would normally be drawn to the framebuf are intercepted by the Layout Library and drawn onto an Image instead. This Image is then composited onto the IDE, achieving WYSIWYG. For the specific code, refer to Layout Library mentioned in a previous article.

Back when I was building the IDE’s visual designer at Kortek, we used exactly this approach. The IDE sends the layout to the rendering engine, which generates an image and returns the boundaries of each Widget in the layout back to the IDE. What you see in the visual designer is really just a background image. When you select a Widget, it displays the selected Widget‘s boundary – just an empty rectangle. Visually it looks like you’re dragging a real Widget, but you’re not.

Projector uses exactly this approach. It provides a custom implementation of java.awt, which is the cornerstone that makes the whole solution possible. The entire View System is taken over by this new AWT implementation, allowing a headless IDE to run on the server. The new AWT serializes graphics drawing operations as commands, sends them over the network to the client, and the client replays these drawing commands to achieve visual consistency.

Use Cases

With Projector, running an IDE on mobile devices is no longer limited by client-side technology. For someone like me who hates carrying a laptop, an iPad is enough. Rent an AWS instance, attach an EBS volume, destroy the instance when you don’t need it, and spin up a new one with the same EBS when you do.

This is especially useful for Android developers whose builds are painfully slow and whose machines keep freezing. You could just move to cloud-based development. The company’s internal development machines are sitting idle anyway. Don’t tell me you’re still using rsync to sync local code to a remote machine for compilation – wouldn’t it be better to develop directly in the cloud?

Quick Start

If you’re interested, you can download the Docker configuration from johnsonlee/ascloud and try it out.
