Booster Collector API

Booster maintains its high performance through two key mechanisms: parallel I/O and single-pass I/O. What does “single-pass I/O” mean? During the Transform process, Booster reads and writes each input (JAR/DIR) exactly once, processing the entire app’s bytecode through a pipeline – the Bytecode Transform Pipeline. This means each Transformer gets only one chance to process a class. But what if a Transformer needs to first collect some information and then write that information as bytecode into a specific class during the Transform? That becomes difficult. A classic example is SPI optimization. While R8 can optimize SPI, it imposes certain constraints on how code must be written.

R8’s SPI Optimization

Starting from version 1.5.68, R8 added optimization for ServiceLoader. Why? Primarily to address a performance issue in Kotlin Coroutines – Slow android Dispatchers.Main init. For more details, see: https://issuetracker.google.com/issues/120436373

Kotlin Coroutines uses SPI to run different API implementations on different JVM platforms – for instance, the Android implementation differs from the Java one since Android needs the Main Looper, which doesn’t exist in plain Java. The Kotlin Coroutines solution was a bit clunky, so R8 introduced an optimization targeting this specific pattern:

1	ServiceLoader.load(X.class, X.class.getClassLoader()).iterator();

After optimization, the code becomes:

1	Arrays.asList(new X[] { new Y(), ..., new Z() }).iterator()

Here, Y and Z are all implementations of X discovered at compile time. For implementation details, see: ServiceLoaderRewriter.java

Limitations of Single-Pass I/O

For this kind of scenario, Booster’s single-pass I/O falls short. Modifying ServiceLoader calls requires first discovering all implementation classes for each Service, which means at least two read passes – but a Transformer only gets one.

There’s another problem: during incremental builds, if X‘s implementations change from Y and Z to just Y (i.e., Z is deleted), how does the class that calls ServiceLoader detect this change and remove Z from the already-optimized code? In other words, transforming:

1	Arrays.asList(new X[] { new Y(), new Z() }).iterator()

into:

1	Arrays.asList(new X[] { new Y() }).iterator()

The first problem – needing an extra read pass – is relatively straightforward. The second problem is harder: during incremental builds, the scope of changes extends beyond what AGP considers incremental, because some JAR/DIR files haven’t changed but were modified by the optimization and need to be re-optimized. This requires yet another read pass. Three reads plus one write versus the original one read and one write – for a framework obsessed with performance like Booster, that’s unacceptable. How can we reduce the unnecessary I/O overhead?

Booster Collector API

To thoroughly solve these problems, starting from version 4.3.0, Booster provides the Collector API to merge those two extra read operations. In most cases, you don’t need to re-parse class files to collect information – simply iterating over all filenames in the JAR/DIR entries is sufficient.

Additionally, Booster provides a Supervisor API similar to the Collector API. The only difference: the Collector API results affect the incremental Transform scope, while the Supervisor API does not.

Collecting SPI Services

For SPI information gathering, Booster provides a built-in implementation – ServiceSupervisor. Here’s how to use it:

@AutoService(ClassTransformer::class)
class ServiceRegistryTransformer : ClassTransformer {

    val services = mutableListOf<Pair<String, Collection<String>>>()

    override fun onPreTransform(context: TransformContext) {
        context.registerCollector(ServiceSupervisor() {
            services += it
        })
    }

    override fun transform(context: TransformContext, klass: ClassNode) = klass.apply {
        // TODO ...
    }

}

Generating/Updating ServiceRegistry

Many frameworks generate a service registry at compile time for service registration and discovery. During full builds, ServiceSupervisor handles this well. But during incremental builds, the ServiceRegistry class – typically baked into framework code as a JAR/AAR – never changes before the Transform phase. For the framework to support incremental builds, it needs to update ServiceRegistry whenever a Service changes. This is where NameCollector comes in, forcing an update on the JAR containing ServiceRegistry:

@AutoService(ClassTransformer::class)
class ServiceRegistryTransformer : ClassTransformer {

    val services = mutableListOf<Pair<String, Collection<String>>>()

    override fun onPreTransform(context: TransformContext) {
        context.registerCollector(ServiceSupervisor() {
            services += it
        })

        // Once a JAR/DIR contains ${SERVICE_REGISTRY},
        // force the transform flow regardless of full or incremental build
        context.registerCollector(NameCollector(SERVICE_REGISTRY))
    }

    override fun transform(context: TransformContext, klass: ClassNode) = klass.apply {
        when (klass.name) {
            SERVICE_REGISTRY -> {
                val init = methods.find {
                    it.name == "<init>" && it.desc == "()V"
                } ?: defaultInit.apply {
                    methods.add(this)
                }

                init.instructions = InstList().apply {
                    services.forEach { (api, implementations) ->
                        implementations.forEach { implementation ->
                            // class of api
                            add(LdcInsnNode(Type.getObjectType(api)))
                            // class of implementation
                            add(LdcInsnNode(Type.getObjectType(implementation)))
                            // ServiceRegistry.register(interface, implementation)
                            add(MethodInsnNode(Opcodes.INVOKEVIRTUAL, SERVICE_REGISTRY, "register", "(Ljava/lang/Class;Ljava/lang/Class;)"))
                        }
                    }
                    add(InsnNode(Opcodes.RETURN))
                }
            }
        }
    }
}

private const val SERVICE_REGISTRY = "com/your/package/ServiceRegistry.class"

The final decompiled code would look something like this:

class ServiceRegistry {

    private static final Map<Class<?>, List<Class<?>> mapping = new HashMap<>();

    private void <T> register(Class<T> api, Class<? extends T> implementation) {
        ...
    }

    private ServiceRegistry() {
        register(A.class, AImpl.class);
        register(B.class, BImpl.class);
        register(C.class, CImpl.class);
        ...
    }

}

References

SPI Performance Optimization
